Egg Hatcher IH-11

Item Id: IH-11

Modular hatcher for hen eggs.

Fully automated hatching system, to produce healthy, highly uniform day old chicks



Product Description

   Benefits



           Fully automated, modular hatching system, with counter-flow based airflow for the

           accurate regulation of temperature, heating, cooling, humidity and ventilation,

           produces healthy, highly uniform day old chicks. Modular hatcher control prevents cross

           contamination from older to younger batches, because eggs of different ages need not

           be mixed.

           Circular Cooling, a system of cooling circuits integrated into the smooth of the hatcher.

           Securely placed and compartmentalized sensors in the central operating console allow

           for high pressure cleaning without risking damage.

           All surfaces, fixings and finishes are designed to resist the ingress of moisture and

           bacteria, preventing the creation of dirt traps.



       Technical Specifications



              Type

                    IH-11

Capacity Hen eggs ( 102 egg tray )

11,424

Capacity Hen eggs ( 101 egg tray )

11,312

Capacity Hen eggs ( 90 egg tray )

10,080

Capacity Quail eggs ( 264 egg tray )

29,568

Capacity Duck/Turkey  eggs ( 60 egg tray )

6,720

Length/width*/height (Inches)

87” x 84” x 82”

Number of Hatcher dolleys

4

Number of trays

112

Hatcher tray dimensions (Inches)

31” x 16” x 5.75”

Modular design

Heating, cooling, humidification and ventilation systems in each incubation section

Heating

Electrical heating and Heating copper coil

Cooling

Water cooling coil system

Humidification

Classic Gunny Ring

Ultrasonic Humidifier (Optional)

Incubator control

Digital control

Analog control

PLC Based (optional)

ESM (Digital Control Only)

Energy Saving Module

Housing

Fully sealed cabinet; robust, easy-to-clean construction ; extruded, anodized powder coated aluminium profiles for maximum stability and ease of installation; HPL panels with maximum insulation value; 2-lock door system, includes solid hinges, airtight sealing rubbers and solid door handles
