Egg Setter 34,272 Eggs Incubator (IS-34)

Item Id: IS-34

Modular setter for hen eggs for the most advanced developments



Product Description

Benefits

The modern hatchery manager’s goal is to produce large numbers of uniform, robust day old chicks. Dayal is the only system that meets this requirement by uniquely combining modular incubator design and technology.

With the Highest number of eggs in each section, Dayal incubators allow for maximum uniformity and optimal climate conditions for each batch of eggs. The mechanical turning mechanism ensures a foolproof and reliable setter tray tuning system. Tray turning itself is inline with the airflow, which enables optimal ventilation conditions for each, individual setter tray.

Technical Specifications

              Type
                    IS-34
Capacity Hen eggs ( 102 egg tray )
34,272
Capacity Hen eggs ( 101 egg tray )
33,936
Capacity Hen eggs ( 90 egg tray )
30,240
Capacity Quail eggs ( 264 egg tray )
88,704
Capacity Duck/Turkey  eggs ( 60 egg tray )
20,160
Length/width*/height (Inches)
92” x 144” x 82”
Number of Setter Racks
2
Number of trays
336
Setter tray dimensions (mm)
28.25” x 12” x 1”
Modular design
Heating, cooling, humidification and ventilation systems in each incubation section
Heating
Electrical heating and Heating copper coil
Cooling
Air Cooling System
Humidification
Classic Gunny Ring    Ultrasonic Humidifier(Optional)
Incubator control
Digital Controller       PLC Based (Optional)
ESM (Digital Control Only)
Energy Saving Module
Housing
Fully sealed cabinet; robust, easy-to-clean construction ; extruded, anodized powder coated aluminium profiles for maximum stability and ease of installation; HPL panels with maximum insulation value; 2-lock door system, includes solid hinges, airtight sealing rubbers and solid door handles
