Egg Setter IS-8

Item Id: IS-8

Modular setter for hen eggs for the most advanced developments

Product Description

  Benefits



          The modern hatchery manager’s goal is to produce large numbers of uniform,

           robust day old chicks. Dayal is the only system that meets this requirement,

           by uniquely combining modular incubator design and technology.



With the Highest number of eggs in each section, Dayal incubators allow for maximum uniformity and optimal climate conditions for each batch of eggs. The mechanical turning mechanism ensures a foolproof and reliable setter tray tuning system, without the need for pressurised air supply. Tray turning itself is inline with the airflow, which enables optimal ventilation conditions for each, individual setter tray.




       Technical Specifications



              Type

                    IS-8

Capacity Hen eggs ( 102 egg tray )

8,568

Capacity Hen eggs ( 101 egg tray )

8,484

Capacity Hen eggs ( 90 egg tray )

7,560

Capacity Quail eggs ( 264 egg tray )

22,176

Capacity Duck/Turkey  eggs ( 60 egg tray )

5,040

Length/width*/height (Inches)

92” x 51” x 82”

Number of Setter Racks

1

Number of trays

84

Setter tray dimensions (mm)

28.25” x 12” x 1”

Modular design

Heating, cooling, humidification and ventilation systems in each incubation section

Heating

Electrical heating and Heating copper coil

Cooling

Water cooling coil system

Humidification

Classic Gunny Ring

Ultrasonic Humidifier

Incubator control

Digital and Analog

ESM (Digital Control Only)

Energy Saving Module

Housing

Fully sealed cabinet; robust, easy-to-clean construction ; extruded, anodized powder coated aluminium profiles for maximum stability and ease of installation; HPL panels with maximum insulation value; 2-lock door system, includes solid hinges, airtight sealing rubbers and solid door handles
