Egg Hatcher IH-6

Item Id: IH-6

Modular hatcher for hen eggs.

Fully automated hatching system, to produce healthy, highly uniform day old chicks

Product Description

Benefits

Fully automated, modular hatching system, with counter-flow based airflow for the accurate regulation of temperature, heating, cooling, humidity and ventilation,produces healthy, highly uniform day old chicks.Modular hatcher control prevents cross contamination from older to younger batches, because eggs of different ages need not be mixed. Securely placed and compartmentalized sensors in the central operating console allow for high pressure cleaning without risking damage. All surfaces, fixings and finishes are designed to resist the ingress of moisture and bacteria, preventing the creation of dirt traps.

Technical Specifications

              Type

                    IH-6

Capacity Hen eggs ( 102 egg tray )

5,712

Capacity Hen eggs ( 101 egg tray )

5,656

Capacity Hen eggs ( 90 egg tray )

5,040

Capacity Quail eggs ( 264 egg tray )

14,784

Capacity Duck/Turkey  eggs ( 60 egg tray )

3,360

Length/width*/height (Inches)

87” x 51” x 82”

Number of Hatcher dolleys

2

Number of trays

56

Hatcher tray dimensions (Inches)

31” x 16” x 5.75”

Modular design

Heating, cooling, humidification and ventilation systems in each incubation section

Heating

Electrical heating and Heating copper coil

Cooling

Water Cooling Coil System

Air Cooling System

Humidification

Classic Gunny Ring

Ultrasonic Humidifier (Optional)

Incubator control

Digital control

Analog control

PLC Based (Optional)

ESM (Digital Control Only)

Energy Saving Module

Housing

Fully sealed cabinet; robust, easy-to-clean construction ; extruded, anodized powder coated aluminium profiles for maximum stability and ease of installation; HPL panels with maximum insulation value; 2-lock door system, includes solid hinges, airtight sealing rubbers and solid door handles
